- True mid-wheel drive: 20.7” turning radius
- Robust independent suspension can absorb up to 350 lbs on the footplate without tipping forward
- Premium, semi-reclining ergonomic seat, up to 135°
- 12” knobby drive tires for superior traction
- Dynamic LiNX & Shark controller for convenient Bluetooth programming and diagnostics
- 20” seat width with 18”-20” depth adjustability
- 22” or 24” seat widths with 20”-22” depth adjustability
- Compact mid-wheel drive design for tight space maneuverability
- Patented obstacle climb suspension on front castors
- Full suspension for a smooth ride
- No rear tipping on footplate standing
- Dynamic LiNX fully programmable controller
- Off-board 4-amp charger
- Swing-back control arm as standard
- Semi-reclining backrest
- Height and width adjustable armrest
- Height-adjustable two-tone seat
- Option to add a power-operated seat elevation feature
Specifications
Product #: P327 , P3274 w/lift
Weight Capacity: 450 lbs, 400 lbs w/lift
Drivetrain: MWD (Mid-Wheel Drive)
Seat Type: Captain or Pan
Seat Width: P327: 22", P3274: 20”
Seat Depth: P327: 22”, P3274: 20”
Backrest Height: 22"
Seat-to-Floor Height: P327: 22”-23” P3274: 24”-34”
Elevating Seat: P3274 - 10"
Overall Length: 35.4"
Overall Width: 27.2"
Overall Height: 48"
Turning Radius: 21"
Ground Clearance: 2.2"
Total Weight: 243 lbs, 273 lbs
Wt of Heaviest Pc: 121 lbs, 151 lbs
Max Speed: 5 mph
Per Charge Range: up to 20 miles
Motor: DC 24V, 300W x 2pcs
Controller: Dynamic Shark 50A
Battery Size (2): 12V/22NF (50AH)
Charger: 5A off-board
Gradient: 8 °
Front Wheels: 6" solid
Drive Wheels: 12" flat-free
Rear Wheels: 6" solid
Group: Group 2: Heavy Duty
Manuals & Literature
Owners manual
Warranty
Power Chair Warranty – Lifetime Limited
Merits Health Products, Inc. warrants the main frame against defects in material and workmanship for the lifetime expectancy of this power chair (5 years).
For one (1) year from the date of purchase, Merits will replace at their option to the original purchaser, free of charge, any of the following parts found upon examination by an authorized representative in the material or workmanship: Electronic controllers, harnesses, chargers, motors. Labor charges incurred in the installation or repair of the above mentioned parts plus all freight charges are not included in the warranty.
Warranty exclusions: Tires, plastic or rubber parts, upholstery/armpads, painted surfaces, seating, bearings.
Merits Health Products, Inc. will repair or replace parts as required, provided that an authorization for such return has been acquired by an established dealer and that the part or parts in question are returned fully insured with freight prepaid to us within the prescribed period of warranty. Labor charges incurred in the installation or repair of the above mentioned parts plus all freight charges are not included in the warranty.
Merits Health Products, Inc will not warranty any parts damaged by improper installation and/or repair on the part of the individual owner’s neglect, accident or misuse, nor those parts altered or serviced by an agency not authorized by us.
FAQ's
What is the weight capacity of the Merits Health Vision Sport Power Wheelchair?
The weight capacity of this power wheelchair is 300 lbs.
Does the Vision Sport Power Wheelchair come with a power-operated seat elevation feature?
Yes, the P326D model offers an optional power-operated seat elevation feature, allowing you to adjust the seat height from 22 inches to 29.5 inches.
What is the maximum speed and range of this power wheelchair?
The Vision Sport Power Wheelchair can reach a maximum speed of 5 mph and has a per charge range of up to 18 miles.
Is the chair suitable for indoor and outdoor use?
Yes, the chair's mid-wheel drive system provides excellent maneuverability for both indoor and outdoor settings.
Are there color options available for customization?
Yes, the chair comes in eight exclusive shroud cover colors, allowing you to choose the one that suits your preferences.
