Easy Therapy for Wheelchair Users
The OxyRevo Heal 40 is purpose-built for wheelchair users, offering a generous 67" L × 62" W × 75" H interior with a 26"-wide wheelchair ramp for smooth, hassle-free entry. Its aluminum base and gradual slope eliminate barriers to access, and the chamber also accommodates a standard chair for comfortable seated therapy sessions.
Crafted from eco-friendly, non-toxic materials, the Heal 40 features precision-engineered custom valves, dual YKK zippers, dual air filtration, and a reinforced internal frame for solid structural stability throughout every session. Generously sized windows flood the interior with natural light, creating an open, welcoming atmosphere.
A 10L oxygen concentrator supplies 90–97% purity oxygen, supported by dual pressure displays and independent release controls accessible both inside and outside the chamber for safe, intuitive operation.
What's the AC Upgrade?
Your chamber ships with a standard air cooler that maintains a marginally lower temperature than the surrounding environment (typically running 2–4°F above room temperature inside).
Upgrade to the Water Chiller AC Unit to:
- Actively regulate internal temperature
- Keep the chamber cool and comfortable, even in warmer rooms
- Maintain a pleasant environment throughout extended sessions
Want flexibility?
Select "AC-Ready" ports come factory pre-cut, enabling AC installation at any future point with no modifications required. An ideal solution for warmer climates and peak summer conditions.
Why Combine Red Light Therapy and HBOT?
HBOT maximizes oxygen delivery to body tissues, promoting cellular repair, enhancing circulation, and reducing inflammation, while RLT energizes mitochondria to amplify energy output and collagen production. Together, they operate in synergy to optimize oxygen utilization at the cellular level, resulting in faster healing, deeper recovery, and far more effective overall therapeutic outcomes.
📖
Every chamber from Mediriser comes with a free Protocol Book containing step-by-step instructions, professional tips, and in-depth guidance for safely using your chamber across 20+ conditions.
Specifications
| Chamber |
|---|
 |
Working Pressure: 1.4 ATA |
|
Weight: 43 kg / 95 lbs |
|
Dimensions: 67 inch L × 62 inch W × 75 inch H (5.58 ft × 5.17 ft × 6.25 ft) |
|
Wheelchair Ramp Width: 26 inch wide |
|
Windows: 4 large double-layered windows |
|
Sound Level: ≤50 dB |
|
Cover Color: Grey / OEM available |
| Standard Version |
|---|
 |
Air Compressor: Model AE01, 110V/220V, 19.29 inch L × 11.42 inch W × 15.75 inch H, 550W, 72 L/min, 35 lbs |
|
Air Cooler: Model ZLA01, 110V/220V, 11.81 inch L × 7.48 inch W × 13.39 inch H, 210W, 120 L/min, 13 lbs |
|
Oxygen Concentrator: Model HG10, 110V/220V, 18.11 inch L × 17.32 inch W × 30.71 inch H, 500W, 10 L/min, 66 lbs |
|
Operation: Separate units with individual setup and control |
|
Efficiency: Effective dehumidifying and cooling, continuous oxygen production, double input/output filters |
|
Additional Features: Lower cost, portable, lightweight, and economical to transport |
| Pro Version |
|---|
 |
All-in-One Machine Unit: Air Compressor (1), Oxygen Concentrator 10L, Cooling Machines (2), Anion Generator, Timing Alarm, Oxygen Meter, Water Container, Air Filters |
|
Dimensions & Weight: 27.56 inch L × 13.78 inch W × 29.53 inch H, 176.37 lbs |
|
Operation: Fully integrated functions with one-press activation |
|
Efficiency: Enhanced dehumidifying and cooling, continuous oxygen production, double activated carbon filters |
|
Additional Features: Nano Water Ion Technology for purified air, 99% virus sterilization rate |
| Optional Add-On: Red Light Therapy |
|---|
 |
Red Light Wavelength: 660 nm |
|
Near-Infrared Wavelength: 850 nm |
|
Power Supply: DC 24V |
|
Power Rating: 200W |
|
LEDs: 40 pcs |
|
Panel Dimensions: 9.45 inch × 5.51 inch × 1.18 inch |
| Water Chiller AC |
|---|
 |
Input Power: AC220V / 50Hz |
|
Total Power: 230W – 900W (varies by model) |
|
Tank Capacity: 4L – 5L (approx. 1.0 – 1.3 gallons) |
|
Cooling Capacity: 1,875 BTU – 6,480 BTU |
|
Temperature Control Range: 14°F to –40°F (model dependent) |
|
Accuracy: ±1.8°F (±1°C) |
|
Display Resolution: 0.1°F (0.1°C) |
|
Sensor Type: PT100 |
|
Flow Rate: 2.6 – 4.0 gallons/min (10 – 15 L/min) |
|
Lift Height: 10 – 23 ft (3 – 7 m) |
|
Cooling Tank Size: approx. 7 inch × 6 inch (Φ18×16 cm) up to 8.7 inch × 7 inch (Φ22×18 cm) |
|
Net Weight: 66 – 121 lbs (30 – 55 kg) |
|
Dimensions: 15.7 inch × 11 inch × 21 inch up to 18.5 inch × 14.5 inch × 26.8 inch |
Features, Benefits & Applications
Spacious 67 inch L × 62 inch W × 75 inch H interior, purpose-designed for wheelchair users or standard chair seating
Robust aluminum base with a smooth, gradual slope for effortless wheelchair entry and exit
Four large double-layered windows for abundant light, clear visibility, and a noticeably open feel
Whisper-quiet operation at ≤50 dB for a calm, undisturbed therapy environment
Dual YKK zippers ensure smooth, reliable access from both inside and outside the chamber
Custom valves and dual air filters actively capture PM2.5 particles, maintaining a clean and safe breathing environment
Includes a 10L oxygen concentrator delivering 90–97% pure oxygen throughout every session
Dual pressure displays provide precise, real-time monitoring from both inside and outside the chamber
Benefits
Accelerated healing, reduced inflammation, strengthened immune response, stress relief, improved skin vitality and energy levels, enhanced recovery for athletes, and meaningful support for chronic and complex health conditions.
Applications
Ideally suited for post-surgical rehabilitation, sports injury recovery, migraine and stroke management, traumatic brain injury, chronic fatigue, autism support, diabetes care, and comprehensive wellness restoration.
What's in the Box?
The OXYREVO Heal 40 Portable Wheelchair Hyperbaric Chamber arrives as a fully equipped package, ready to begin your hyperbaric oxygen therapy journey:
Chamber:
Internal/external pressure gauges
Operating Unit:
All-in-One Machine (For Pro Version)
Accessories:
Spare activated carbon cotton filters
Education:
🎁
FREE Protocol Book ($1,000 Value)
Warranty
Warranty basics
All machines and components come with a warranty plus lifetime technical support at no cost. If any quality issues occur within the warranty period that can be easily repaired, we will provide replacement parts free of charge, along with step-by-step repair guidance through pictures and videos. If the issue cannot be fixed, we will promptly send you a new machine at no cost.
Warranty length
2-Year
Commercial Warranty
3-Year
Residential Warranty
Lifetime
Technical Support
Component durability:
Soft Chamber Capsule: 10,000 hours
Air Compressor: 10,000 hours
Oxygen Concentrator: 5,000 hours
Remedies and costs
Replacement parts and repair guidance are provided free of charge during the warranty period. If the issue cannot be resolved through repair, a new machine will be sent at no cost. For service or maintenance enquiries, contact Customer Services at 📞 (251) 292-1169 or 📩 support@mediriser.com.
Shipping
Shipping and claims overview
Standard lead time is 2–4 weeks. An expedited shipping option is available that reduces production time from 3–5 weeks down to 1–2 weeks for an additional fee. We also offer US-based lifetime product support. Our network of technicians across the United States is available to assist you whenever needed.
Filing a claim
If there is an issue with your shipment or your chamber arrives damaged, please contact our customer service team as soon as possible. Email 📩 support@mediriser.com or call 📞 (251) 292-1169 and include your full name, order number, and photos of any damage.
Returns
Return Policy
Our Hyperbaric Chambers are individually tested with care by our professional technicians prior to shipment. Due to the nature of the product, we do not accept returns on Hyperbaric Chambers.
Refunds
If you would like to discuss a return or have concerns about your order, please contact our customer support team at 📩 support@mediriser.com or call us at 📞 (251) 292-1169.
